High Sensitivity BRC Certified Touch Metal Detector For Food Industry
Introduction&Application
Product Highlights
1. Full range of aperture sizes to suit products being inspected.
2. Auto parameter setting by intelligent product learning.
3. Higher interference proof by multi-filtering algorithm and X-R orthogonal decomposition algorithm.
4. Multilevel password protection provides secure access
5. Anti-interference photoelectric isolation drive allows remote installation of operation panel.
6. Further improvement in metal sensitivity and detecting stability by adaptive DDS and DSP technology.
7. Multiple product memories for rapid product change over and data storage.
8. Able to detect all kinds of metal, such as iron, stainless steel, copper, aluminum, etc.
9. Optional rejection modes: pneumatic pusher, pneumatic flipper, pneumatic drop belt, belt retraction.
10. Optional full-cover or open type collecting bin.
11. Optional output safety cover with gate-open sensor that stops the machine.
12. SUS304 frame and major hardware parts by CNC tooling.
Key Components
● Durable EMA alarming tower
● US ferromagnetic random access memory
● Japanese Oriental motor
● SUS 304 roller bearing
● Food grade PU conveyor belt
● Japanese SMC pneumatic components
● Danish Danfoss frequency converter
● Optional keypad and touch screen HMI.
Technical Specification
|
No
|
Item
|
Data
|
|
1
|
Product Name
|
Fanchi-Tech FA-MD-II Conveyor Metal Detector For Food
|
|
2
|
Material of Construction
|
304 Brushed stainless steel
|
|
3
|
Power Supply
|
220-240 VAC, 50-60 Hz, 1 Ph, 400W
110 VAC, 60 Hz, 1 Ph, 400W |
|
4
|
Temperature Range
|
-10 to 40° C (14 to 104° F)
|
|
5
|
Humidity
|
0 to 95% Relative Humidity (Non-condensing)
|
|
6
|
Belt Speed
|
5-45m/min(variable)
|
|
7
|
Conveyor Belt Material
|
Food level PU belt
|
|
8
|
Operation Panel
|
Key Pad(Touch Screen is optional)
|
|
9
|
Product Memory
|
100
|
|
10
|
Rejecting Mode
|
Sound and light alarm
|
|
11
|
Software Language
|
English(Spanish/French/Russian, etc optional)
|
|
12
|
Conformity
|
CE (Declaration of Conformityand Declaration of Manufacturer)
|
|
13
|
Automatic Reject Options
|
Belt-Stop / Stop On Detect, Pusher, Air-blast, Flipper, Flap, etc
|
Detial
FAQ
Q: Does this metal detector meet food industry safety certifications, and which food production scenarios is it applicable to?
A: This FA-MD-II conveyor metal detector is BRC certified and CE compliant, meeting strict food industry safety and hygiene standards. It is widely applicable to meat, poultry, fish, bakery, convenience food, ready meals, confectionery, snacks, dried foods, cereals, dairy & egg products, fruits, vegetables, nuts and other food processing lines. All detectors can be customized to fit specific production environment requirements.
Q: What kinds of metal contaminants can it detect, and what technologies support its detection performance?
A: It can detect all common metal contaminants including iron, stainless steel, copper and aluminum. It adopts adaptive DDS and DSP technology to improve metal detection sensitivity and stability, and uses multi-filtering algorithm plus X-R orthogonal decomposition algorithm to deliver stronger anti-interference capability in complex production environments.
Q: How convenient is it to switch between different products on the production line?
A: The machine supports intelligent product learning for automatic parameter setting, and can store up to 100 sets of product presets to realize rapid product changeover. It is also equipped with multilevel password protection for secure access, and the anti-interference photoelectric isolation drive allows remote installation of the operation panel. The operation panel comes with a keypad, and a touch screen is optional.
Q: What rejection modes and optional accessories are available for this metal detector?
A: It is standard configured with sound and light alarm when metal is detected. For automatic rejection, multiple options are available including belt-stop, pneumatic pusher, air-blast, flipper and drop belt. Optional accessories include full-cover or open-type collecting bins, and output safety cover with gate-open sensor that stops the machine automatically.
Q: Is the equipment suitable for humid or wash-down food processing workshops?
A: Yes. The whole machine adopts 304 brushed stainless steel frame and main hardware parts processed by CNC tooling, matched with a food-grade PU conveyor belt, which fully meets food hygiene requirements for frequent cleaning. It operates stably in -10 to 40°C temperature and 0–95% non-condensing humidity, adapting well to wet, dry and frozen food processing environments.
