China Fanchi Tablets Deduster and Metal Detector Combination System for Pharmaceutical Industry factory and manufacturers

Fanchi Tablets Deduster and Metal Detector Combination System for Pharmaceutical Industry

short description:

Fanchi Tablets Deduster and Metal Detector Combination System for Pharmaceutical Industry

The machine integrates tablet dust removal, polishing, lifting, and metal detection and rejection. The integrated control box controls two machines, easy to adapt to the scene, intuitive access, convenient experience and operation, compact overall structure, closed conveying channel, can accept toxic production process, harmless to human body, and ensure the safety and health of medicines. The product is suitable for being installed after some pharmaceutical equipment like the tablet press machine, the capsule filling machine and the sieve machine. High sensitivity and stability detection of Ferrous metal(Fe),Non-Ferrous metals (Copper, Aluminum) and Stainless Steel.

Send email to us

Product Detail

Product Tags

Introduction&Application

Fanchi Tablets Deduster and Metal Detector Combination System for Pharmaceutical Industry

Product Highlights

1. Suitable for detecting magnetic and non-magnetic metal foreign bodies in separated tablets
2. Product tracking function: can automatically adjust and compensate internally according to changes in product effects
3. Use the latest micro-processing control system, with automatic learning and setting function
4. The metal detection coil is made of stainless steel, and the inside is completely sealed, with stable performance
5. The sieving machine uses the principle of dust removal and vibration, while removing excess powder, the continuous vibration makes the tablets continue to rise.
6. The product working area and the mechanical area are separated to ensure that the product and mechanical parts are not affected by each other, and the product is safer
7. Disassembly and assembly in 7.5 seconds, simple and convenient, no tools required
8. The equipment has the advantages of low noise, convenient disassembly and assembly, easy cleaning, beautiful appearance, etc.
9. Both the internal and external structures are treated with stainless steel mirror surface, the appearance is beautiful and generous, and the internal is easy to clean
10. Imported driving device, quiet and stable operation of the equipment
11. The metal parts in contact with the tablets are all made of food-grade materials, which meets the requirements of GMP
12. The screen body can be rotated left and right, and can be used online with the tablet press at the discharge end in any direction, saving production space
13. The equipment has the advantages of low noise, convenient disassembly and assembly, easy cleaning, and beautiful appearance. Equipped with lockable casters for easy movement

Key Components

1. Japanese Shindengen rejection system
2. Metal detector head by Germany hardfill
3. USA ferromagnetic random access memory
4. US AD DDS Signal Generator

5. US AD low noise amplifier
6. US ON Semiconductor demodulation chip
7. French ST microelectronics ARM Processor

Feature

Automatic machine for checking the quality of tablets with a Fanchi-tech metal detector

Pharmaceutical machine type of equipment used in the pharmaceutical industry for the manufacture of medicines. Pharmaceutical equipment automatic lines and individual machines that are used in the manufacture and packaging of medicines in the form of tablets, capsules, ointments, suppositories, dragees, briquettes, tinctures, decoctions, syrups, granules, powders, drops and potions. Analytical equipment it is very important to control the quality of raw materials and finished medicines in pharmaceutical production.

Technical Specification

No	Item	Data
1	Product Name	Fanchi Tablet Deduster&Metal Detector Combination Machine
2	Material of Construction	Test Coil and Frame: 304 Brushed stainless steel Material Contact Parts: S/S316
3	Power Supply	220-240 VAC, 50-60 Hz, 1 P
4	Temperature Range	-10 to 40° C (14 to 104° F)
5	Humidity	0 to 95% Relative Humidity (Non-condensing)
6	Tunnel Material	Food grade plexiglass
7	Tunnel Size	70x20/100x25mm Adptive
8	Best Accuracy	Fe: 0.2mm; Non-Fe: 0.3mm; SUS304: 0.5mm
8	Operation Panel	Key-Pad Panel(Touch Screen is optional)
9	Product Memory	100
10	Rejecting Mode	Fast Auto Flap Valve Rejector
11	Software Language	English(Spanish/French/Russian, etc optional)
12	Conformity	CE (Declaration of Conformityand Declaration of Manufacturer)
13	Output Capacity	300 000pcs/hr
